Zen–O™ Portable Concentrator

GCE Healthcare’s portable oxygen concentrator can deliver up to 2 litres of oxygen in either pulse or continuous flow. … Zen–O™ portableoxygen concentrator is manufactured in the UK to high standards.

Zen-O Portable Concentrator offers both continuous and pulse flow for oxygen therapy patients. The Zen-O offers 2 liters per minute (LPM), meeting the oxygen demands for most patients. The Zen-O is designed for respiratory disorders such as chronic obstructive pulmonary disease (COPD), providing oxygen on demand for patients both at home or on the go. Its lightweight structure and small size make it easy to bring with you in its carry-bag or pull cart that comes standard with your order.

Zen-O Portable Oxygen Concentrator offers greater operational efficiency than many of the competing devices on the market. The maximum outlet pressure is 20.5 psi, able to push oxygen through extended tubing. Zen-O concentration levels range from 87 to 96 percent. Noise emission is at 42 decibels (ISO 3744 standard).

The AC power adapter functions using from 100 to 240 volts on 50 to 60 Hz systems. The DC power adapter provides for use in automobiles, boats and RV’s. A 12-cell battery will power the Zen-O for 4 hours with 2 LPM of oxygen at 18 breaths per minute (BPM) while in pulse flow mode. Add a battery, and the Zen-O will allow you to operate away from home for up to 8 hours.

The Zen-O Oxygen Concentrator is manufactured by GCE with easy to replace sieve beds that can be exchanged using simple tools in under 5 minutes. The replaceable sieve beds can save you hundreds of dollars over other brands. Zen-O™ uses advanced technology in its construction to adjust the amount of oxygen delivered according to a patient’s breath rate. When the patient needs more oxygen, the Zen-O machine automatically responds by increasing the O2 output.

Demonstration Videos

For privacy reasons YouTube needs your permission to be loaded.
I Accept
For privacy reasons YouTube needs your permission to be loaded.
I Accept
For privacy reasons YouTube needs your permission to be loaded.
I Accept

SPECIFICATIONS

Zen-O™ is manufactured to meet the exacting standards of the European Medical Device Directive. GCE Healthcare ensures that our products undergo rigorous safety and quality checks before they reach our customers. Below is the technical information for the
Zen-O™ portable oxygen concentrator.

Size: 212 mm (W), 168 mm (D), 313 mm (H)

(8.3″ (W), 6.6″ (D), 12.3″ (H)
Unit weight: 4.66 kg (10.25 Ibs) (without carry bag and cart)
Power requirements: AC adaptor: 100-240V AC(+/- 10%) 50-60 Hz in

24V DC, 6.25A out

DC adaptor: 11.5 – 16V DC in, 19V, 7.9A out

(Important: see accessories list for model and part number of AC power supply.)
Purity: 87% – 96% at all flow rates, over operating conditions
Setting: User adjustable in 0.5 increments from 1.0 to 6.0 in pulse mode and from 0.5 to 2.0 in continuous mode.
Inspiratory trigger sensitivity: -0.12cm/H20
Setting indicator: LCD display
Maximum oxygen discharge pressure: 20.5 psi
Humidity range: 5% to 93% ± 2% non-condensing
Operating altitude: 0’ to 13,000’ (0m to 4,000m) relative to sea level, 1,060 down to 575 mbar
Sound level: Sound Pressure level of 38 dB(A) at setting 2 in pulse mode, tested according to Prufmethode 14-1 03/2007 MHS-Hi

Sound Pressure level of 46dBA/Sound Power level of 54 dBA at setting 6 in pulse mode

Sound Pressure level of 52 dBA/Sound Power level of 60 dBA at setting 2 continuous
Type of protection (electrical): Class II
Degree of protection (electrical): Type BF
Degree of protection (water): IP22 in carry bag (protection against small objects and tilted drip-ping water)

IP20 out of carry bag (protection against small objects and no protection against water entering the concentrator)
Degree of safety (flammable anaesthetic mixture): Not suitable for use in the presence of a flammable anaesthetic mixture
Operating temperature: Continuous operating at temperatures between 5°C (41°F) and 40°C (104°F).
Storage temperature: Between -20°C (-4°F) and 60°C (140°F).
Alarm sound pressure level: Less than 10 second after detection (low oxygen alarms if oxygen is less than 82% volume fraction at specified environmental conditions)
Oxygen concentrator status indicator: High priority alarm that indicates when oxygen concentration drops below 82%.

USER MANUAL

User Manual

Start Guide

Helpful Information

FREQUENTLY ASKED QUESTIONS

Helpful Hints

Advanced Technology

Zen-O™ uses advanced technology to adjust the amount of oxygen delivered in response to a patient’s breath rate and automatically increases the amount when the patient needs it most – such as walking uphill.

Features and Benefits

Introducing Zen-O™ portable oxygen concentrator from GCE Healthcare



Zen-O™ portable oxygen concentrator is designed
to enable patients with respiratory disorders such
as chronic obstructive pulmonary disease (COPD), to better manage their oxygen therapy within and outside their homes.Zen- O™ portable oxygen concentrator delivers freedom and peace of mind to patients by providing mobile oxygen on demand.Zen-O™ weighs just 4.66 kg and can deliver up to 2 litres per minute of oxygen in either pulse or continuous flow. Zen-O is supplied  with variety of accessories, including a carry bag and a pull cart for increased mobility.Zen-O’s practical and robust design offers greater operational efficiency and low cost of ownership for home oxygen providers.
Zen-O™ is designed with easy to replace sieve bed. The sieve bed can be replaced in the field using simple tools in under 5 minutes, saving time and money.

Zen-O™ is produced in the UK following GCE’s investment in a new manufacturing and innovation centre.

Dual mode

Zen-O™ portable oxygen concentrator can deliver up to 2 litres of oxygen in either pulse or continuous flow.

Easy to use

Zen-O™ is simple to use with clear button operation and LCD panel.

UK expertise and global support

Zen-O™ portable oxygen concentrator is manufactured in the UK to high standards. GCE has locations in the United States, Latin America, China, India and across Europe. Our strategic partners in Africa and the Middle east help us ensure accessories and spare parts are readily available to our customers.

Field replaceable sieve bed

Zen-O’s practical design makes it easy for home oxygen providers to replace the sieve bed in under
5 minutes using simple tools.

Visual and audio alarms

Zen-O™ has various audible and visual alarms to prompt the user of a required action. Some alarms include low battery, service required, and no breath detected.

Warranty

Zen-O™ portable oxygen concentrator is supplied with a 3 year or 15,000 hours device warranty.
